  • NPT MALE OF METRIC THREAD BITE TYPE TUBE FITTINGS
  • NPT MALE OF METRIC THREAD BITE TYPE TUBE FITTINGS
  • NPT MALE OF METRIC THREAD BITE TYPE TUBE FITTINGS
  • NPT MALE OF METRIC THREAD BITE TYPE TUBE FITTINGS
Enlarge NPT MALE OF METRIC THREAD BITE TYPE TUBE FITTINGS

NPT MALE OF METRIC THREAD BITE TYPE TUBE FITTINGS

Price: 0.01~0.05 USD
Payment Terms: T/T,L/C,WU
Place of Origin: Zhejiang, China (Mainland)
inquire
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Model No.: 1CN/1DN 1CN-RN/1DN-RN
Head Code: Hexagon
Technics: Others
Material: Carbon Steel
Brand Name: Yuyao Chaoda
Means of Transport: Ocean,Air
Shape: Others
Type: Others
Connection: Male
1CN/1DN 1CN-RN/1DN-RN: NPT MALE

Item: NPT MALE OF METRIC THREAD BITE TYPE TUBE FITTINGS
Material:Carbon steel
Finish:Zinc plated
Process:CNC machining

NPT MALE OF METRIC THREAD BITE TYPE TUBE FITTINGS

Specifications
PART NO.
THREAD
TUBE O.D.
DIMENSIONS
MPa
E
F
D1
I1
L1
S1
S2
1CN-12-02
M12X1.5
Z1/8"X27
6
13.4
28.4
12
14
25
1CN-12-04
M12X1.5
Z1/4"X18
6
17.2
32.2
17
14
1CN-14-04
M14X1.5
Z1/4"X18
8
17.2
32.2
14
17
1CN-16-04
M16X1.5
Z1/4"X18
10
18.2
33.2
17
19
1CN-16-06
M16X1.5
Z3/8"X18
10
19.9
53.0
19
19
1CN-18-04
M18X1.5
Z1/4"X18
12
19.2
34.2
19
22
1CN-18-06
M18X1.5
Z3/8"X18
12
19.9
34.9
19
22
1CN-18-08
M18X1.5
Z1/2"X14
12
21.4
36.4
22
22
1CN-22-08
M22X1.5
Z1/2"X14
15
22.4
37.4
24
27
1CN-22-20
M22X1.5
Z1.1/4"X11.5
15
29.8
37.4
46
27
1CN-26-08
M26X1.5
Z1/2"X14
18
22.9
39.4
27
32
16
1CN-26-12
M26X1.5
Z3/4"X14
18
22.4
38.9
30
32
1CN-30-08
M30X2
Z1/2"X14
22
24.4
40.5
32
36
1CN-30-12
M30X2
Z3/4"X14
22
24.4
40.9
32
36
1CN-36-16
M36X2
Z1"X11.5
28
29.8
46.3
41
41
1CN-36-20
M36X2
Z1.1/4"X11.5
28
31.3
46.3
46
41
1CN-45 -20
M45 X2
Z1.1/4"X11.5
35
30.3
51.8
46
50
1CN-52-20
M52X2
Z1.1/4"X11.5
42
31.8
55.5
55
60
1CN-52-24
M52X2
Z1.1/2"X11.5
42
32.8
55.5
55
60
1DN-14-04
M14X1.5
Z1/4"X18
6
22.2
37.2
17
17
40
1DN-16-04
M16X1.5
Z1/4"X18
8
22.2
37.2
17
19
1DN-18-04
M18X1.5
Z1/4"X18
10
21.7
38.2
19
22
1DN-18-06
M18X1.5
Z3/8"X18
10
22.4
38.9
19
22
1DN-20-04
M20X1.5
Z1/4"Xia
12
23.7
40.2
22
24
1DN-2O-06
M20X1.5
Z3/8"X18
12
24.4
40.9
22
24
1DN-20-08
M20X1.5
Z1/2"X14
12
25.9
42.4
22
24
1DN-22-08
M22X1.5
Z1/2"X14
14
27.4
45.4
24
27
1DN-24-08
M24X1.5
Z1/2"X14
16
26.9
45.4
27
30
25
1DN-30-12
M30X2
Z3/4"X14
20
28.4
49.9
32
36
1DN-36-12
M36X2
Z1"X11.5
25
35.3
59.3
41
46
1DN-36-16
M36X2
Z1"X11.5
25
35.3
59.3
41
46
1DN-42-16
M42X2
Z1"X11.5
25
35.8
59.3
46
46
1DN-42-20
M42X2
Z1.1/4"X11.5
30
36.3
62.8
46
50
1DN-52-24
M52X2
Z1.1/2"X11.5
38
39.8
70.8
55
60
Note:ln case if you are interested to order the adapter in complete set with cutting ring and nut, it is necessary to insert suffix "RN" after our part NO.,for example 1DN-30-12RN.
